Vertical Test Stand

Schulz Electric's vertical test stand is capable of absorbing up to 8,000 lb-ft of torque at continuous load rating (max 1500 hp @ 800 rpm). Schulz can also develop speed torque curves and perform locked rotor testing utilizing this vertical test stand.

Test Bed for No-Load Operation Run Test of Vertical Motors

Schulz Electric's test bed, engineered for 100,000lbs, was specifically designed for large vertical motors. In response to increasing customer demands, Schulz had the test bed designed, professionally installed and precision leveled so that we can better meet your needs, and exceed your expectations. As seen to the right, the test bed features 2 hole sizes to accommodate various sized vertical motors. The test bed was set on a bed of steel pads anchored in high-tensile (5000 PSI) concrete, bolted down and grouted, during the Christmas/New Year's holiday period of 2005/2006. This time period was chosen to avoid any delays in the final testing of work in progress.

return_to_top

EQ Harsh Environment System

Schulz Electric offers environmentally qualified form and random wound insulation systems for rewinding harsh environment EQ motors, or for incorporation with new motors. The 4.2kV insulation systems is qualified for use in harsh environments outside containment that may be exposed to a MSLB/HELB with peak temperatures of us to 395 degrees F at peak pressures of up to 70 psig. The 600V system is qualified for inside containment LOCA conditions with peak temperatures of 425 degrees F and 77 psig. The 600V system is available for intermittent duty motors (MOV).

return_to_top

Contaminated Motor Repair Including RCP Motor Overhaul and Rewind

    Why Choose Schulz?
  • Decontamination, engineering and repair in one building.
  • NRC Licensed to decontaminate motors to unconditional free-release status.
  • Schulz has performed work for all nuclear power plants in the United States.
  • All repairs performed in house to 8000 hp/40ton.
  • Schulz is the preferred safety-related motor repair facility in the industry.
  • Truly a single source for safety-related motor and decontamination services.

Schulz Electric has performed work for every nuclear utility in the United States. Schulz Electric has completed hundreds of safety-related jobs since 1994. This work has ranged from supplying new large EQ safety related motors, performing contaminated motor repair, to repairing and testing MOV's. We have developed and maintain a highly extensive 10CFR50 Appendix B QA program, which allows us to perform safety-related repairs and commercial grade dedications.

What our clients are saying:

"It is truly a pleasure to deal with people who share your goals relating to quality service."
"It is nice to know we have vendors such as you that we can rely on."

Schulz Electric Radiation Workers have undergone training and have all passed written examinations. Routine monitoring for radioactive contamination is performed throughout the entire facility. Along with the Radiation Safety Officer, trained radiation workers receive and survey incoming motors that may potentially be contaminated.

return_to_top

Safety-Related Repairs

Schulz Electric has developed and maintains a highly extensive 10CFR50 Appendix B QA program which allows Schulz to perform safety-related repairs and commercial grade dedications.

return_to_top

Supply of New Safety-Related Motors, Commercial Grade Dedication

When it's not cost effective to repair a safety-related motor,or when a spare motor is needed, Schulz Electric incorporates one of the most rigorous, in depth, motor dedication programs available to the industry. Full-load testing is performed on every motor dedicated by Schulz Electric, including elevated or reduced voltage testing and locked rotor testing when required. Now with our harsh environment system approved, Schulz Electric can meet your Environmentally Qualified needs and provide safety-related/environmentally qualified harsh environment motors.

return_to_top

High Quality, Cost Effective Solutions for MOV Dilemmas

MOV Testing - We have provided the most in-depth testing of motor operated valve motors in the industry, from reduced voltage started in extreme temperature, to locked rotor testing. Utilizing our state of the art ADAMS tester, and our Harsh Environment Qualified System, Schulz Electric can meet every need in the industry.

Rewind - With Schulz Electric's EQ insulation system for MOVs, why not have your MOVs rewound instead of buying new motors? It is a quick, cost effective, easy solution.

Turnaround Time - Schulz consistently outperforms the industry's standard and emergency turnaround times. Schulz Electric can repair your MOVs in record time during an emergency.

Repair - Schulz Electric can manufacture and replace shafts of AISI 4140 material for those MOV motors that have had keys replaced with AISI 4140 material in high impact loading applications (IN 94-10).

Testing - Schulz Electric has tested over 150 safety-related MOV motors. Reduced voltage testing, increased ambient temperature testing, speed/torque curves. Every valve motor rewound by Schulz is tested on one of our dynamometers. If you have a low margin application, we'll develop actual speed/torque curves for the motor to support your 89-10 program.

return_to_top

Motor Testing Capabilities, Including MOV's

Testing Capabilities - All measuring and test equipment calibrated, traceable to national and international standards.

Data Recording - Custom Automated Data Acquisition and Monitoring Systems (ADAMS) that is calibrated to National and International Standards. This system captures, organizes, and displays/graphs the electrical, mechanical, and thermal test results.

AC Power - 1500kVA continuous at 0 to 110V/600V/2500V/7000V/13.2kV

DC Power - 0 to 600V at 1200A, 0 to 1200V at 300A

Dynamometers - Fractional, 15HP,100HP, 700HP, 1000HP (vertical) and 1500 HP

Surge Tester - 0 to 20,000V

High Potential Tester - 0 to 100,000V DC, 0 to 60,000V AC

Continuous Megger - 5000V / 3000 Gigaohms

Low Resistance - Biddle Ductor to 1 Microhm

VPI Tanks - 8' X 10' tank with Epoxylite 477 epoxy resin (with UL Listed system)
6' X 10' tank with Ranbar B7-607 polyester resin (for non-safety-related applications)

Vibration Analysis - IRD Model 820 Vibration Analyzer, CSI Model 2115 Machinery Analyzer, CSI UltraSpec Machine Analyzer, CSI 2130 Machinery Analyzer

Infrared Thermography - 2 Fluke TI 45 Thermal Cameras

Dynamic Balancing - Schenk models H20B, H5B (5 ton maximum), IRD Model 350 Dynamic Balancer

return_to_top

In-House Motor Decon

Schulz Electric truly is a single source for your contaminated motor needs. Not only is Schulz the preferred safety-related motor repair facility in the industry, Schulz now offers an in-house decontamination facility.

Gone are the days of utilizing several different companies for your engineering, repair and decontamination services. Schulz Electric spent over a year planning, designing, building and developing procedures to provide you with a new state of the art decontamination facility right here at our New Haven, Connecticut facility.

Schulz Electric is NRC licensed to decontaminate motors to unconditional free-release status. Schulz Electric Radiation Workers have undergone training and have all passed a written examination.

You, our customers told us you needed to decrease your downtime. By adding this new facility, consider it done. Here at Schulz Electric, we continuously strive to exceed your expectations, and our new decontamination facility is proof that we take our customer's needs seriously.

return to top
Vertical Motor Test Bed
Schulz Electric Company's test bed, engineered for 100,000lbs, was specifically designed for large vertical motors. In response to increasing customer demands, Schulz had the test bed designed, professionally installed and precision leveled so that we can better meet your needs, and exceed your expectations. As seen above, the test bed features 2 hole sizes to accommodate various sized vertical motors. The test bed was set on a bed of steel pads anchored in high-tensile (5000 PSI) concrete, bolted down and grouted, during the Christmas/New Year's holiday period of 2005/2006. This time period was chosen to avoid any delays in the final testing of work in progress.
Operational Excellence Award Motor overhaul and Decontamination
Above: 9000 HP motor that was brought in on red-rush priority for decontamination and overhaul.
Condensate collected in the catch tank is pumped through a fi lter and a mixed-resin bed to a holding tank. This tank will be sampled periodically, and if it meets the radiological release criteria is sent to the building wastewater holding tank.
Schulz Electric's decontamination facility is a 1650-ft2 restricted area where licensed material is received and decontaminated. Two thirds of this restricted area is the Decontamination Area. One third of the restricted area is a radiologically clean transition, storage, and dress area. All walls in the Decontamination Area are sheathed in 20 foot high stainless steel. Decontamination in this area will be accomplished by steam cleaning or by a cryogenic cleaning system.
Located insided the Decon Area is a 10-foot by 10-foot steel grid Decon Pad, on which motors are placed during steam cleaning. Underneath is a catch tank approximately 8 inches deep.
A HEPA fi ltered ventilation system takes suction on the Decontamination Area and discharges 85% of the fi ltered air back into the clean dress area. The remaining 15% of the fi ltered air is discharged to the environment. The discharge stack is equipped with an isokinetic probe, in-line air sampler to collect a representative sample of discharged air.
Air discharges will be held to less than the concentrations listed in 10CFR20 Appendix B, Table 2, Column 1. Records of all discharges of licensed material to air is maintained. The HEPA ventilation system runs, at a minimum, suring sandblasting operations or when other dry decontamination methods are in use.
